Masscanned

Masscanned (name inspired, of course, by masscan) is a network responder. Its purpose is to provide generic answers to as many protocols as possible, and with as few assumptions as possible on the client's intentions.

Let them talk first.

Just like masscan, masscanned implements its own, userland network stack, similarly to honeyd. It is designed to interact with scanners and opportunistic bots as far as possible, and to support as many protocols as possible.

For example, when it receives network packets:

• masscanned answers to ARP who is-at with ARP is-at (for its IP addresses),
• masscanned answers to ICMP Echo Request with ICMP Echo Reply,
• masscanned answers to TCP SYN (any port) with TCP SYN/ACK on any port,
• masscanned answers to HTTP requests (any verb) over TCP/UDP (any port) with a HTTP 401 web page.

Masscanned currently supports most common protocols at layers 2-3-4, and a few application protocols:

• Eth::ARP::REQ,
• Eth::IPv{4,6}::ICMP::ECHO-REQ,
• Eth::IPv{4,6}::TCP::SYN (all ports),
• Eth::IPv{4,6}::TCP::PSHACK (all ports),
• Eth::IPv6::ICMP::ND_NS.
• Eth::IPv{4,6}::{TCP,UDP}::HTTP (all HTTP verbs),
• Eth::IPv{4,6}::{TCP,UDP}::STUN,
• Eth::IPv{4,6}::{TCP,UDP}::SSH (Server Protocol only).

Try it locally

1. Build masscanned

$ cargo build

2. Create a new net namespace

# ip netns add masscanned

3. Create veth between the two namespaces

# ip link add vethmasscanned type veth peer veth netns masscanned
# ip link set vethmasscanned up
# ip -n masscanned link set veth up

4. Set IP on local veth to have a route for outgoing packets

# ip addr add dev vethmasscanned 192.168.0.0/31

5. Run masscanned in the namespace

# ip netns exec masscanned ./target/debug/masscanned --iface veth -v[vv]

6. With another terminal, send packets to masscanned

# arping 192.168.0.1
# ping 192.168.0.1
# nc -n -v 192.168.0.1 80
# nc -n -v -u 192.168.0.1 80
...

Use it

A good use of masscanned is to deploy it on a VPS with one or more public IP addresses.

To use the results, the best way is to capture all network traffic on the interface masscanned is listening to/responding on. The pcaps can then be analyzed using zeek and the output files can typically be pushed in an instance of IVRE.

A documentation on how to deploy an instance of masscanned on a VPS is coming (see Issue #2).

Protocols

Layer 2

ARP

masscanned anwsers to ARP requests, for requests that target an IPv4 address that is handled by masscanned (i.e., an address that is in the IP address file given with option -f).

The answer contains the first of the following possible MAC addresses:

• the MAC address specified with -a in command line if any,
• the MAC address of the interface specified with -i in command line if any,
• or the masscanned default MAC address, i.e., c0:ff:ee:c0:ff:ee.

Ethernet

masscanned answers to Ethernet frames, if and only if the following requirements are met:

• the destination address of the frame should be handled by masscanned, which means:

  • masscanned own MAC address,
  • the broadcast MAC address ff:ff:ff:ff:ff:ff,
  • a multicast MAC address corresponding to one of the IPv4 addresses handled by masscanned (RFC 1112),
  • a multicast MAC address corresponding to one of the IPv6 addresses handled by masscanned ;

• EtherType field is one of ARP, IPv4 or IPv6.

Note: even for a non-multicast IP address, masscanned will respond to L2 frames addressed to the corresponding multicast MAC address. For instance, if masscanned handles 10.11.12.13, it will answer to frames addressed to 01:00:5e:0b:0c:0d.

Layer 3

IPv4/IPv6

masscanned answers to IPv4 and IPv6 packets, only if:

• no IP address is specified in a file (i.e., no -f option is specified or the file is empty),

or

• the destination IP address of the incoming packet is one of the IP addresses handled by masscanned.

An additionnal requirement is that the next layer protocol is supported - see below.

IPv4

The following L4 protocols are supported for an IPv4 packet:

• ICMPv4
• UDP
• TCP

If the next layer protocol is not one of them, the packet is dropped.

IPv6

The following L4 protocols are supported for an IPv6 packet:

• ICMPv6
• UDP
• TCP

If the next layer protocol is not one of them, the packet is dropped.

Layer 3+/4

ICMPv4

masscanned answers to ICMPv4 packets if and only if:

• the ICMP type of the incoming packet is EchoRequest (8),
• the ICMP code of the incoming packet is 0.

If these conditions are met, masscanned answers with an ICMP packet of type EchoReply (0), code 0 and the same payload as the incoming packet, as specified by RFC 792.

ICMPv6

masscanned answers to ICMPv6 packets if and only if:

• the ICMP type is NeighborSol (135) and:
  • no IP (v4 or v6) was speficied for masscanned
  • or the target address of the Neighbor Solicitation is one of masscanned

In that case, the answer is a Neighbor Advertisement (136) packet with masscanned MAC address

or

• the ICMP type is EchoRequest (128)

In that case, the answer is a EchoReply (129) packet.

TCP

masscanned answers to the following TCP packets:

• if the received packet has flags PSH and ACK, masscanned checks the SYNACK-cookie, and if valid answers at least a ACK, or a PSH-ACK if a supported protocol (Layer 5/6/7) has been detected,
• if the received packet has flag ACK, it is ignored,
• if the received packet has flag RST or FIN-ACK, it is ignored,
• if the received packet has flag SYN, then masscanned answers with a SYN-ACK packet, setting a SYNACK-cookie in the sequence number.

UDP

masscanned answers to an UDP packet if and only if the upper-layer protocol is handled and provides an answer.

Protocols

HTTP

STUN

SSH

masscanned answers to SSH Client: Protocol messages with the following Server: Protocol message:

SSH-2.0-1\r\n

Internals

Tests

Unit tests

$ cargo test
   Compiling masscanned v0.2.0 (/zdata/workdir/masscanned)
    Finished test [unoptimized + debuginfo] target(s) in 2.34s
     Running target/debug/deps/masscanned-b86211a090e50323

running 36 tests
test client::client_info::tests::test_client_info_eq ... ok
test layer_2::arp::tests::test_arp_reply ... ok
test layer_3::ipv4::tests::test_ipv4_reply ... ok
test layer_3::ipv6::tests::test_ipv6_reply ... ok
test layer_4::icmpv6::tests::test_icmpv6_reply ... ok
test layer_2::tests::test_eth_reply ... ok
test layer_4::icmpv6::tests::test_nd_na_reply ... ok
test layer_4::tcp::tests::test_synack_cookie_ipv4 ... ok
test layer_4::icmpv4::tests::test_icmpv4_reply ... ok
test layer_4::tcp::tests::test_synack_cookie_ipv6 ... ok
test proto::http::test_http_request_field ... ok
test proto::http::test_http_request_no_field ... ok
test proto::http::test_http_request_line ... ok
test proto::http::test_http_verb ... ok
test proto::stun::tests::test_change_request_port ... ok
test proto::stun::tests::test_proto_stun_ipv6 ... ok
test proto::stun::tests::test_proto_stun_ipv4 ... ok
test proto::stun::tests::test_change_request_port_overflow ... ok
test smack::smack::tests::test_anchor_end ... ok
test smack::smack::tests::test_anchor_begin ... ok
test smack::smack::tests::test_multiple_matches ... ok
test smack::smack::tests::test_http_banner ... ok
test smack::smack::tests::test_multiple_matches_wildcard ... ok
test smack::smack::tests::test_proto ... ok
test smack::smack::tests::test_wildcard ... ok
test proto::tests::test_proto_dispatch_ssh ... ok
test proto::tests::test_proto_dispatch_stun ... ok
test synackcookie::tests::test_clientinfo ... ok
test synackcookie::tests::test_ip4_dst ... ok
test synackcookie::tests::test_ip4_src ... ok
test synackcookie::tests::test_ip4 ... ok
test synackcookie::tests::test_ip6 ... ok
test synackcookie::tests::test_key ... ok
test synackcookie::tests::test_tcp_dst ... ok
test synackcookie::tests::test_tcp_src ... ok
test smack::smack::tests::test_pattern ... ok

test result: ok. 36 passed; 0 failed; 0 ignored; 0 measured; 0 filtered out

Functional tests

# ./test/test_masscanned.py
tcpdump: listening on tap0, link-type EN10MB (Ethernet), snapshot length 262144 bytes
INFO    test_arp_req......................................OK
INFO    test_arp_req_other_ip.............................OK
INFO    test_ipv4_req.....................................OK
INFO    test_eth_req_other_mac............................OK
INFO    test_ipv4_req_other_ip............................OK
INFO    test_icmpv4_echo_req..............................OK
INFO    test_icmpv6_neighbor_solicitation.................OK
INFO    test_icmpv6_neighbor_solicitation_other_ip........OK
INFO    test_icmpv6_echo_req..............................OK
INFO    test_tcp_syn......................................OK
INFO    test_ipv4_tcp_psh_ack.............................OK
INFO    test_ipv6_tcp_psh_ack.............................OK
INFO    test_ipv4_tcp_http................................OK
INFO    test_ipv6_tcp_http................................OK
INFO    test_ipv4_udp_http................................OK
INFO    test_ipv6_udp_http................................OK
INFO    test_ipv4_tcp_http_ko.............................OK
INFO    test_ipv4_udp_http_ko.............................OK
INFO    test_ipv6_tcp_http_ko.............................OK
INFO    test_ipv6_udp_http_ko.............................OK
INFO    test_ipv4_udp_stun................................OK
INFO    test_ipv6_udp_stun................................OK
INFO    test_ipv4_udp_stun_change_port....................OK
INFO    test_ipv6_udp_stun_change_port....................OK
INFO    test_ipv4_tcp_ssh.................................OK
INFO    test_ipv4_udp_ssh.................................OK
INFO    test_ipv6_tcp_ssh.................................OK
INFO    test_ipv6_udp_ssh.................................OK
tcpdump: pcap_loop: The interface disappeared
604 packets captured
604 packets received by filter
0 packets dropped by kernel

Logging Policy

• ERR: any error - will always be displayed.
• WARN, -v: responses sent by masscanned.
• INFO, -vv: packets not handled, packets ignored.
• DEBUG, -vvv: all packets received and sent by masscanned.

To Do

• Drop incoming packets if checksum is incorrect
• Fix source address when answering to multicast packets.
